Sulzer submersible dranaige center-line pump XJC 80

The slim design of the submersible drainage center-line pump XJC 80 makes it perfect for applications with limited installation space. The pump is ideal for pumping water and dirty water mixed with light abrasives. Pumps with built in AquaTronic unit will always have correct direction of impeller rotation, ensuring peak performance and reduced wear. 50 Hz: head max 76 meters, flow max 52 l/s. 60 Hz: head max 94 meters (308 feet), flow max 37 l/s (587 gpm).

Specification

Electric submersible pump.
Maximum submergence: 20 m. Protection class IP 68.
Max temperature of pumped medium at max power input and continuous duty 40 ºC.
Max medium density 1100 kg/m3. pH of the pumped medium 5-8.
Strainer hole: 7.5 x 22 mm.
Max number of starts 30/hour.

Electric motor

3-phase squirrel-cage induction motor, 50 Hz:

Service factor 1.1. Class F insulation.
Motor rating P2: 8.3 kW. 2 pol.
Speed: 2920 rpm.ŋ: 89.9 (50 %), 90.6 (75 %), 89.6 (100 % load)

Starting method and motor protection

XJC 80 AT: Soft start (230-400 V) is built in with the AquaTronic unit, where three thyristors reduces start current to three times the nominal current. Here two relays ensures correct motor rotation.The AquaTronic unit monitors motor temperature, by use of NTC thermistors built into stator windings, and stops the motor at high temperature. It will also stop the motor at high amperage or if a phase is missing.

XJC 80: Direct on line start with built in contactor. Pumps to be used with VFD or 1000 V must have terminal block instead of contactor. Thermal switches (140 °C, ±5) built into the stator wind-ings are connected to the contactor and stops the pump at high temperature.

Power cable

20 m type H07RN8-F (standard cable):
4 x 4 sq.mm. (230 V)
4 x 2.5 sq.mm. (400-550 V)
4 x 1.5 sq.mm. (690 V)

20 m type NSSHÖU.../3E (heavy duty cable):
3x2.5+3x2.5/3E+3x1.5 (3 control cables included) (1000 V orterminal block)
3x6+3x6/3E+3x1.5 (230 V)
3x2.5+3x2.5/3E (400-550 V)
3x1.5+3x1.5/3E (690 V)

Shaft seal

Double mechanical seal in oil bath.
Primary seal: Silicon carbide on silicon carbide.
Secondary seal: Silicon carbide on carbon.

Bearings

Upper bearing: Single-row deep groove ball bearing.
Lower bearing: Double angular contact ball bearing.

Discharge connections

3" (standard SD), 4" (standard ND), 6" (standard LD) hose connections.
3", 4", 6" G/B.S.P. threaded connections.

Weight

ND/LD: 63 kg, SD: 78 kg (without cable)

Options and accessories

AquaPlug. AquaTronic control panel.
Level sensor. Service data kit.
Zinc anodes. Surface protection coating.
Series connection.
Discharge connection accessories and hose.

Pump control

XX = Fault indication when pump is automatically stopped to protect the motor.
